BAV3 Cryogenic Ball Valve
| Size range: | 1/2"-4" (DN15 - DN100) |
| Pressure Rating: | PN16 - PN100 |
| Temperature Range: | -196℃~ +260℃ (-320℉ ~ +500℉) |
| Valve structure: | Three-piece floating structure |
| Operation type: | manual, worm gear, etc |
Standards and Specifications
| Design and manufacture standard: | API 6D, EN 1626 |
| Temperature and pressure rating: | ASME B16.34, EN 12516-1 |
| Low temperature standard: | BS 6364, MSS SP-134 |
| Inspection and testing standard: | API 598, API 6D, EN 12266-1 |
| Firesafetest: | BS EN ISO 10497, API 607, API 6FA |
| Low emission conform to: | ISO 15848-1, TA-Luft |
Material
| low temperature CS: | LCB, LCC, LC1, LC2, LC3, etc |
| Austenitic stainless steel: | CF8M, CF8, CF3M, CF3, etc |
Industrial applications
LNG storage and transport, industrial gas storage, petroleum chemical industry, air separation
